Description
Ibanez AS103BM-ABR
The AS103BM features a full-sized, double-cutaway, semi-hollow body design with a laminated burl maple top with ƒ holes and flame maple multi-binding on burl maple back and sides mated to a set-in maple and walnut neck with a 22-fret rosewood fingerboard with flame maple binding and abalone custom block position markers. Components include a pair of Ibanez Super 58 Custom humbucking pickups with gold covers and individual volume and tone controls, a Tune-o-matic style bridge with an ART1 Tailpiece, a plastic nut, a rosewood pickguard, rosewood knobs, and Ibanez tuning machines with white buttons.
- Body
- Body type: Hollow body
- Dimensions:
- Length: 489mm / 19¼”
- Width: 400mm / 15¾”
- Depth: 67mm / 2⅝” (43mm at tail)
- Top:
- Material: Burl maple (laminated)
- Binding: Flame maple multi-ply
- Back/sides: Material: Burl maple (laminated)
- Neck joint: Set-in
- Bridge: ART-1 (10.5mm string spacing)
- Tailpiece: ART-1
- Pickguard: Rosewood
- Pickuprings: Rosewood
- Knob style: Rosewood bell
- Hardware color: Gold
- Neck
- Neck type: Artcore Custom AS
- Neck material: 5-piece maple/ walnut
- Scale length: 628mm/ 24¾”
- Fingerboard material: Rosewood w/ flame maple binding
- Fingerboard inlays: Abalone custom block
- Frets: 22 / medium
- Nut: Ivory plastic (43mm)
- Machine heads: Ibanez die-cast w/ white acrylic half-moon buttons
- Electronics/ Strings
- Pickup configuration: HH
- Bridge pickup: Ibanez Super 58 Custom (H) passive/ceramic
- Neck pickup: Ibanez Super 58 Custom (H) passive/ceramic
- Controls: Two volumes / two tones / 3-way toggle pickup selector
- Output jack: ¼” mono (side mounted)
- String gauge (factory): .010/.013/.017/.030/.042/.052
- Factory tuning: 1E,2B,3G,4D,5A,6E (E Std.)
